Battery Charger Panel

Name: Battery Charger Panel
Brand: J. N. I. Electrotech Private Limited
Price: 10000 INR
Availability: InStock

Get a Price/Quote

MOQ : 01 Piece

Battery Charger Panel Specification

Components
MCB, Indicator lamps, Ammeter, Voltmeter, Contactor, Terminal Blocks

Features
Overload Protection, Short Circuit Protection, Easy Installation

Rated Current
20A

Protection Level
IP42, IP42

Protection Class
Class I

Panel Type
Wall Mounted

Connectivity Type
Wired

Rated Operation Voltage
230V AC

Base Material
Mild Steel, Mild Steel

Cabinet Material
Powder Coated Mild Steel

Cooling System
Natural Air Cooling

Way
Single / Double way

Current Rating
20A

Rated Insulation Voltage
690V

Operating Voltage
230V AC

Control System
Automatic / Manual

Cover Material
Toughened Glass / Mild Steel, Acrylic/Glass window

Thickness
2 mm

Product Type
Battery Charger Panel, Battery Charger Panel

Material
Mild Steel, Mild Steel (MS)

Surface Finish
Powder Coated, Powder Coated

Standard
IS/IEC 61439

Surface Color
Grey, Grey

Rated Voltage
230V AC / 24V DC

Frequency (MHz)
50Hz

Maximum Output Current
20A

Dimension (L*W*H)
600 x 450 x 250 mm

Application
Industrial / Battery charging

IP Rating
IP42, IP42

Display Type
Analog Meters, Analog/Digital Meter

Alarm
Buzzer for Fault Indication

Charging Current
Up to 20A Adjustable

Mounting Type
Wall/Floor Mounted

Enclosure Type
Dust & Vermin Proof

Metering
Voltmeter, Ammeter

Humidity
95% Non-condensing

Indicator Lamps
Phase & Charger Status

Operating Temperature
-10C to +55C

Charging Voltage Range
12V DC to 220V DC

Protection Fuse
HRC Fuse Provided

Input Supply Voltage
220-415V AC, 3 Phase

Battery Charger Panel Trade Information

Minimum Order Quantity
01 Piece

Supply Ability
10 Pieces Per Day

Delivery Time
2 Days

About Battery Charger Panel

We are a well-known manufacturer and supplier of Battery Charger Panel. These are made by using optimum quality raw material under the guidance of our senior experts. These are also checked on various quality check parameters by our quality experts to maintain its good quality and to make sure the delivery of the best quality product. These are mainly used in industries. It is also available to our customers on budget-friendly price. These Battery Charger Panel are made by using iron material which makes it corrosion resistant.

Versatile Voltage & Current Range

This charger panel supports a wide charging voltage range (12V DC to 220V DC) and adjustable charging current up to 20A. It is compatible with various battery types and capacities, making it suitable for numerous industrial environments.

Rugged Construction for Safety

Manufactured using powder-coated mild steel with a sturdy 2mm thickness, the panel ensures protection from dust, vermin, and moisture (IP42). Toughened glass or acrylic windows allow safe meter viewing, and HRC fuses safeguard against overloads and short circuits.

User-Friendly Design & Monitoring

The panel features clear analog/digital meters for voltage and current, phase and charger status indicator lamps, and a fault buzzer. Natural air cooling, easy wall/floor mounting, and accessible controls guarantee straightforward operation and maintenance.

FAQ's of Battery Charger Panel:

Q: How do I install the Battery Charger Panel in an industrial setting?

A: The panel can be wall or floor mounted, depending on your site layout. Ensure it is installed in a location that remains within the operating temperature range of -10C to +55C and in areas not exposed to direct water spray, as it is rated IP42. Follow the wiring instructions provided and verify all connections using the terminal blocks and protective devices included.

Q: What batteries can be charged using this panel and how is the charging current set?

A: This charger supports a voltage range of 12V to 220V DC and adjustable charging current up to 20A, making it suitable for a wide array of industrial batteries, including lead-acid and NiCd types. The charging current can be set precisely using the panel controls, according to your battery requirements.

Q: When does the built-in buzzer alarm activate and what faults does it indicate?

A: The buzzer provides immediate auditory alerts in case of faults such as phase failures, overcurrent, or other system anomalies. This ensures prompt attention to operational issues, preventing damage or unsafe conditions.

Q: Where should this charger panel be ideally mounted for best performance?

A: Mount the panel in environments with controlled humidity (not exceeding 95% non-condensing) and within the specified temperature range. A clean indoor area, away from direct exposure to water and dust, will optimize performance and longevity.

Q: What process is involved in monitoring the charging operation?

A: The panel is equipped with analog/digital voltmeter and ammeter meters for real-time voltage and current tracking. Status indicator lamps display phase and charger activity, while all monitoring can be done through the transparent window for safety and convenience.

Q: How does the panel ensure safety during operation?

A: Overload and short-circuit events are mitigated by built-in HRC fuses and MCBs. The enclosure's IP42 rating protects internal components, and indicator lamps along with a buzzer deliver instant notifications for any abnormal conditions, ensuring both user and equipment safety.

Q: What are the benefits of the mild steel, powder-coated enclosure and IP42 protection?

A: The enclosure offers robust mechanical protection against impacts and prevents ingress of dust and vermin, extending the panel's lifespan. The powder-coated finish resists corrosion, while the IP42 rating ensures reliable performance in demanding industrial settings.
